| Dimensions (LxWxH) | 6.990 x 2.290 x 2.500 mm |
| Weight (Including Drillrods) | 14.000 (15.920) kg |
| Engine type | WEICHAI WP10HG230E670, Stage V |
| Horsepower | 170 kW / 2200 rpm |
| Bentonite pump capacity | 600 ltr/min |
| Bentonite pump pressure | 80 bar |
| Rack and pinion | yes |
| Hydraulic anchoring system | yes |
| Length Drillpipe | 3.0 mtr |
| Pipe diameter | 83 mm |
| OD tooljoint | 92 mm |
| Weight per pipe | 60 kg |
| Bend radius | 59 mtr |
| Rod box capacity | 32 pcs |
| Thrust-/pullback | 45.000 kg |
| Max spindle torque | 18.500 Nm |
| Max spindle speed | 120 rpm |
