| Dimensions (LxWxH) | 6.100 x 2.230 x 2.300 mm |
| Weight (Including Drillrods) | 8.500 (10.180) kg |
| Engine type | WEICHAI WP4.6NG150E670, Stage V |
| Horsepower | 110 kW / 2200 rpm |
| Bentonite pump capacity | 250 ltr/min |
| Bentonite pump pressure | 80 bar |
| Rack and pinion | yes |
| Hydraulic anchoring system | yes |
| Length Drillpipe | 3.0 mtr |
| Pipe diameter | 60 mm |
| OD tooljoint | 68 mm |
| Weight per pipe | 35 kg |
| Bend radius | 40 mtr |
| Rod box capacity | 48 pcs |
| Thrust-/pullback | 23.000 kg |
| Max spindle torque | 7.000 Nm |
| Max spindle speed | 175 rpm |
