| Dimensions (LxWxH) | 4.500 x 1.900 x 2.170 mm |
| Weight (Including Drillrods) | 5.000 (7.525) kg |
| Engine type | WEICHAI WP4.6NG134E671, Stage V |
| Horsepower | 98 kW / 2200 rpm |
| Bentonite pump capacity | 100 ltr/min |
| Bentonite pump pressure | 40 bar |
| Rack and pinion | yes |
| Hydraulic anchoring system | yes |
| Length Drillpipe | 1.80 mtr |
| Pipe diameter | 52 mm |
| OD tooljoint | 57.4 mm |
| Weight per pipe | 27 kg |
| Bend radius | 32 mtr |
| Rod box capacity | 44 pcs |
| Thrust-/pullback | 13.500 kg |
| Max spindle torque | 3.200 Nm |
| Max spindle speed | 230 rpm |
